China ACT MOTOR Spindle motor water cooling round 5.5KW ER25 CNC machine 400HZ Manufacturer and Supplier

ACT MOTOR Spindle motor water cooling round 5.5KW ER25 CNC machine 400HZ

Short Description:

Power: 5.5KW water-cooled spindle motor Brand: Changzhou ACT MOTOR Current: 20 a Weight: 26.5 KG Cooling method: water circulation cooling Speed: 24000 RPM Chuck nut: ER25-A Frequency: 400 hz Lubrication: Grease lubrication Taper hole pulsation: 2UM Voltage: 220V 380V Bearing: 7007P4*2 7205P4*2 Connection mode: line 123 is connected to the frequency converter UVW, line 4 is ground, please connect correctly or not.

Send email to us Download as PDF

Product Detail

Product Tags

5.5KW水冷圆

Power: 5.5KW water-cooled spindle motor
Brand: Changzhou ACT MOTOR
Current: 20 a
Weight: 26.5 KG
Cooling method: water circulation cooling
Speed: 24000 RPM
Chuck nut: ER25-A
Frequency: 400 hz
Lubrication: Grease lubrication
Taper hole pulsation: 2UM
Voltage: 220V 380V
Bearing: 7007P4*2 7205P4*2
Connection mode: line 123 is connected to the frequency converter UVW, line 4 is ground, please connect correctly or not.
